Modular Body Small Camper Trailer Mini Rv Trailer With Sandwich Structure

Modular Body Mini Small Camper Trailer With Sandwich Structure Travel Caravan Trailer torsion bar suspension

Quick details:

Modular body: large CNC engraving integrated molding

Sandwich structure: 37mm thick flame retardant insulation

Lightweight wing panel: German mature wing panel structural design technology

Mortise and tenon joint: Traditional structure connection is more secure

E0 grade furniture board: from inside out, environmentally friendly and worry free

Low center of gravity design: center of gravity sinking, stable and safe

Streamlined appearance: effectively avoids wind resistance and reduces fuel consumption

CNC machining module assembly: increased manufacturing accuracy to 0.05mm

Industry leading supplier: domestic and foreign first tier brands

Strict quality inspection and testing: multiple tests, quality assurance

Description:

European lightweight body structure

Sandwich body structure with a thickness of up to 37mm, with corrosion resistance, flame retardancy, thermal insulation performance.

Imported AL-KO trailer special chassis

Inertial mechanical braking, sensitive, smooth and reliable,

Safer and smoother driving, resistant to high-intensity impacts,

Quiet driving, over 20 years of extended lifespan,

Maintenance free.

Minimalist exterior design, showcasing small and exquisite design

The interior is exquisitely crafted, interpreting the owner's taste

Lightweight design, superior fuel economy, and smoother driving

Green, environmentally friendly, and healthy along the way

Low curb weight, no traction pressure

The appearance has clear edges and corners, and the blue gray lines are smooth and simple. Vehicle size: 5860 * 2440 * 2605mm, easy to drive with a C6 driver's license. Curb weight: 1260KG, with low requirements for front trailers, with a front vehicle weight greater than 1.4 tons. The departure angle reaches 11 degrees, and the vehicle has strong passability.

Professional chassis, smooth and safe

Adopting a German AL-KO trailer chassis: it ensures ultra-high safety when turning, rolling, and overtaking, regardless of crosswind or tailwind conditions; Maintenance free; More suitable for diversified road types in China, with excellent driving experience; Over 15 years of proven high-quality trailer chassis; 4 parking legs, effectively ensuring the safety and stability of trailer RV parking.

The unique hexagonal rubber suspension has good shock absorption effect during dragging and driving, effectively reducing damage to the interior furniture, greatly reducing the sense of turbulence transmitted to the front car, and providing a comfortable driving experience.

Equipped with mains interface, water inlet, external gas stove, gas tank compartment, and other equipment. There are nearly 20 storage spaces inside and outside the rear compartment, with a maximum capacity of over 2400L and a maximum storage size of 1400 * 780 * 580mm.

The style of the interior determines the living atmosphere and also affects the travel experience. The interior is made of walnut wood with a light white countertop and beige sofa, with a soft and warm color tone, giving you a comfortable feeling of home when entering the car.

The interior material of the car is made of E0 grade environmentally friendly materials, and the content of harmful substances (formaldehyde) in the air inside the car is less than 0.1mg/m3, ensuring the fresh and natural air inside the car.

The cabinet countertop in the cooking area of the car adopts a stone patterned fireproof countertop, which is spliced with walnut and milk white to present a rich sense of layering. It is also equipped with 900W Induction cooking, 118L motorhome refrigerator, vegetable washing pool, etc. The 220V power socket on the left side of the cabinet can be used to connect household appliances. The cooking area has abundant storage space for cabinets.

118L RV refrigerator, capable of refrigeration and preservation.

In terms of electrical configuration: The entire vehicle wiring harness adopts a dedicated wiring harness for the entire vehicle and is equipped with a circuit safety protection system, a 1500W inverter, a 100AH lead-acid battery, diesel heating (optional), and a 15L electric water heater.

There are two rest areas in the whole vehicle: the sofa in the reception area can be combined into a double bed, and the size is 2230 × 1500.

Upper and lower bed size: 1760 × 800, the bed can be lifted up.

Bathroom area, hand sink, shower, portable toilet, vanity mirror, 15L electric water heater, and two-way ventilation fan are all available.

The RV dedicated water pump and pressure stabilizing system ensure the continuous stability of water supply. The food grade water pipeline and 100L food grade PE clean water tank ensure water quality safety; Meet daily needs.
